Inicio /Productos/FEP aisló el alambre/Corrosion Resistant Oil Resistant Strong Acid Resistant FEP Insulated Wire and FEP Cable

Corrosion Resistant Oil Resistant Strong Acid Resistant FEP Insulated Wire and FEP Cable

500
MOQ
Corrosion Resistant Oil Resistant Strong Acid Resistant FEP Insulated Wire and FEP Cable
Caracteristicas Galería Descripción de producto Pida una cita
Caracteristicas
Especificaciones
Material conductor: Cobre, cobre plateado o cobre estañado
Material de aislamiento: El FEP
Tensión nominal: CA 600V o más bajo
Tipo de conductor: Varado, varado o sólido
Número central: 1 núcleos, 2 núcleos, 3 núcleos, 4 núcleos, 5 núcleos..
Tipo de aislamiento: FEP, PTFE, PFA, ETFE
Material de la trenza: Cobre plateado o cobre estañado
Material de la vaina: FEP, PTFE, PFA, ETFE
Temperatura de trabajo: -65°C ~ +200°C
Calibre de alambre: 22AWG
Área de la sección transversal: 0,35/0,40 mm2
Estructura de conductores: 19/0.16
OD máximo: 1,95 mm (250 V), 2,2 mm (600 V)
Opciones de color: Blanco, azul, rojo, negro, amarillo, verde, transparente, amarillo/verde
Temperatura nominal: -65°C ~ +200°C
Resaltar:

Corrosion Resistant FEP Insulated Wire

,

Oil Resistant FEP Cable

,

Strong Acid Resistant Fluoroplastic Wire
Información básica
Lugar de origen: Hunan, China
Nombre de la marca: Sanco cable
Número de modelo: Serie AF-200
Pago y Envío Términos
Descripción de producto
2x22AWG Tinned Plated Copper FEP PFA PTFE ETFE Cable

FEP Insulation Fluorineplastic Wires feature excellent corrosion resistance, oil resistance, strong acid/alkali resistance, and oxidation resistance. These cables offer superior electrical insulation performance with high voltage resistance, low frequency loss, moisture resistance, and excellent fire resistance with long service life.

Applications

Ideal for electronic industry applications including temperature compensation wires, low/high temperature heating wires, and flame retardant wires. Commonly used in household appliances such as air conditioners, microwave ovens, electric ovens, lamps, and other heating appliances.

Product Features
  • Wear and scratch resistant
  • High and low temperature resistant (-65°C to +200°C)
  • Anti-aging and corrosion resistant
  • Electromagnetic interference resistant
  • Easy to strip
Cable Specifications
Specification Details
Conductor Materials Tinned Plated Copper or Silver Plated Copper
Conductor Type Stranded or Solid
Number of Cores 1 Core, 2 Cores, 3 Cores, 4 Cores (customizable)
Insulation FEP, PFA, PTFE, ETFE Insulated
Sheath FEP, PFA, PTFE, ETFE
Rated Voltage 600V or Below
Rated Temperature -65°C to +200°C
Color Options White, Blue, Red, Black, Yellow, Green, Transparent, Yellow/Green
Corrosion Resistant Oil Resistant Strong Acid Resistant FEP Insulated Wire and FEP Cable 0
Product Types
Type Name
AF-200 Silver Plated Copper Core FEP Insulation Install Wire
AF-200-1 Tin Plated Copper Core FEP Insulation Install Wire
AFP-200 Tin/Silver Plated Copper Core FEP Insulation Shield Install Wire
AFS-200 Tin/Silver Plated Copper Core FEP Insulation Stranded Install Wire
AFSP-200 Tin/Silver Plated Copper Core FEP Insulation Stranded Shield Install Wire
Cable Structures
Wire Gauge Cross-section Area Conductor Structure Max. OD of Cable
36AWG 0.013mm² 7/0.05 0.65-1.3mm
22AWG 0.35/0.40mm² 19/0.16 1.4-2.2mm
8AWG 8mm² 133/0.28 6.0-7.3mm

Note: FEP high temperature lead wire specifications and core numbers can be customized.

Company Information

Xiangtan Shenzhou Special Cable Co., LTD is a leading wire and cable supplier for China's aerospace and military sectors with 21 years of experience. We produce our own cable compounds, ensuring superior quality and competitive pricing.

Our product range includes High Temperature wires, PTFE cable, FEP Cable, PFA Wire, ETFE Cable, Fluoroplastic Cables, Hook up wire, electronic cable, and Power cable. We maintain advanced production facilities and collaborate with universities and research institutes to offer customized cable solutions.

Corrosion Resistant Oil Resistant Strong Acid Resistant FEP Insulated Wire and FEP Cable 1
Our Honors
  • Contributed to China's manned space flight projects including Shenzhou 7
  • Participated in "Arrow of God" project for astronaut space exploration
  • Recognized by China Academy of Launch Vehicle Technology
Our Service
  • Free technical consultation before, during, and after sales
  • Free samples and design services
  • Quality monitoring during manufacturing
  • Free insurance for internal transportation
  • OEM & ODM services available
  • Small order quantities accepted
FAQ
Q: Are you a manufacturer or trading company?

A: We are a professional manufacturer of military and consumer cable wire and cable compound, located in Hunan Province, China.

Q: What is your company's strengths?

A: We are a stable supplier for China's aerospace and military with 21 years experience, producing our own cable compounds for superior quality.
